Polypropylene: Testing and Perfecting Bonding Methods

6 mins read

Polypropylene (PP) bonding is traditionally a difficult task due to its low surface energy and inert material properties.

(Image credit: Tantec)

Using glue, inks or coatings for PP comes with challenges that while seem overwhelming at first, are well known, and easy to overcome for any budget.

Can you bond to PP?

The short answer is without any doubt, yes. It’s actually one of the easier polymers to bond to but bonding direct to the material without the right preparation is going to be very tricky.

There are a couple of techniques and ideas that people often use, which are good starting points for most adhesion issues on any material for that matter. Here, Tantec discusses the main points:


Top of the question line should always be “is the material clean?” – this is true of bonding polymers like PP, bonding metals, glass ceramics, composites or anything for that matter. You want to bond to the material and get a direct material to ink/ adhesive/ coating link. If there’s even a microscopic layer of grease or dirt, perhaps invisible to the naked eye, you’ll stick to that layer. This layer is not necessarily bonded well to the material underneath and will fail quickly.

Mild chemicals like isopropyl alcohol and water mixed is always a good start. Using a stronger degreasing agent or solvent like acetone or MEK might be needed too. Using polish or something with wax or slip additives in is a definite no – cleaning furniture and cleaning a material for bonding are completely different ‘cleaning’ processes.


If cleaning a component with a cloth and degreasing liquid isn’t enough because there is a thicker contaminate, or the top layer of the material is poor to bond to, abrading is a great idea. This works particularly well for materials like SRIM, metals or wood where the top layer has a reactive finish like an oxide. Underneath this bad layer is perfectly good material and if you can expose this, you can bond to it.

A bit of a myth in many applications is the idea that this will give a greater surface area. In theory, yes this is happening, but in practice it can actually make things worse. Abrading a surface creates peaks and troughs, high and low points to the material. If you apply a liquid to this surface, air bubbles get caught at the bottom of the troughs and you mainly bond to the peaks. You’re now bonding to less area than you would have if it was perfectly flat.

Abrading is also a poor choice if the material under the top layer is also poor for bonding. PP for example doesn’t bond due to its inert material chemistry. Not because there is a thick layer of bad to bond to material on top. Abrading PP only leads to exposing more PP so adhesion strength will largely be unaffected.

Priming or chemical wiping

Adding a chemically active ‘tie layer’, or intermediate layer between substrate and adhesive or ink is going to give really good results in many cases. The primers and chemicals used are usually in small quantities so more dangerous chemicals can be used to really bite into the surface and give the right chemistry to match the adhesive with the material.

This can be especially effective on bonding dissimilar materials where you’re trying to level the chemical compatibility playing field.

Using aggressive, or tailored adhesive or ink products

Many adhesive suppliers in particular will now offer a PP bonding material, such products as Advanced Adhesives PP3000 by, Permabond TA4600 and Forgeway Purok VX 90 are strong contenders for bonding low surface energy materials, such as PP.

These adhesives are often very useful and for many applications are really worth looking into.

Plasma, Corona and Flame Treatment

When trying to bond to PP it’s common to hear people go through testing of all of the above with mixed success. Flame treatment has been a strong contender for an industrial solution for decades, and its flexibility and ease of integration into robot cells mean it is still highly regarded.

Plasma and corona treatment are industrial surface treatments that prepare a surface for bonding – similar to flame, they add new chemistry to the material surface to change it from a non-reactive, inert polymer into something subtly different that has the right chemistry on the surface to bond really well.

While flame, plasma and corona have a lot in common, the main differences are that flame uses gas as an energy source while the others use high voltage. Plasma is an energetic gas, created by high voltage, but the plasma itself is not high voltage. Finally, corona is high voltage and parts go through the high voltage discharge. All aim to cause no damage to the material while still giving that improved surface, and importantly, increased surface energy.

Is one technique better than another?

When bonding any low surface energy material, PP being the most common, it’s likely that cleaning is helpful but not especially performance enhancing. It will remove fingerprints or general dirt, but it still leaves inert material behind that is poor to stick to.

Abrading may be useful if something is on the material that won’t come off, but like cleaning, you’re likely to only leave exposed, inert material behind.

Priming and chemicals can be highly effective, often the best performance of any technique. However, the health and safety concerns, high VOC content and PPE requirements often mean that using it for more than small projects is not ideal. Less aggressive versions do exist and might give enough performance, but it does usually mean a person physically wiping the part manually is required, along with a ‘flash off’ period in which the part has to stand around drying before being used is required.

Active adhesives for low surface energy materials might be just what you need. They often have similar properties to their standard cousins and can be used directly with a wider range of materials. This is usually at a cost, with the adhesives costing significantly more than usual. The range is not always as good as standard adhesives either, so you may have to compromise on some features – strength, open time, cure time etc.

Flame treatment works really well for large injection moulded parts that might be presented along a robotic line such as a paint spraying system. Flame is very forgiving, but a large six inch burner throwing a flame the same distance forward is obviously a costly, and potentially dangerous way to go. Many users opt for gas bottles which also give a factory floor risk of gas canisters too.

Plasma and corona have a number of options, but the usual argument for not using them is the cost. If you are trying to treat a small number of parts, it’s likely that a primer or a low surface energy adhesive is sensible. Plasma and Corona start around £6,000, which buys a lot of primer, so these technologies are definitely for applications requiring the level of repeatability, consistency and automation that comes with them. This cost is often offset by the fact that cost effective polymers like PP can be used instead of costly alternatives such as PC/ABS, a standard adhesive can be used or that less operators are required due to the automated systems instead of manually abrading or wiping components.

Alternatively, Ebble Manufacturing do offer contract plasma and corona treatment of parts, along with subassembly which can be cost effective when compared to any of the discussed bonding methods.

To answer the question, is one technique the best? It depends on the application. Priming and chemical wiping are aggressive, which often gives them very good results. However, this is often matched by plasma, corona and flame treatment. Low surface energy adhesives might have some drawbacks, but if designed right, they can function really well. Abrading a metal with a rust layer at the surface is going to be highly effective, but almost completely ineffective on a PP moulding.

Testing and understanding performance with PP

Bonding and pulling materials apart using dolly pull tests, peel or lap shear tests are the most common offline tests. Trying to pull finished products apart is also very useful, as is putting the part into extreme situations and testing to destruction.

People also measure surface energy using contact angle or test inks, and while it is true to think that higher surface energy will give improved adhesion, it’s not always the case. You need to confirm this using other methods so you can then use those results to design a quality check for production.

Tantec and Ebble Manufacturing run all these test types and more from their labs and facility in Redditch, Worcestershire.


Bonding PP and other low surface energy materials can be tough. Traditional methods like abrading can be useless and some of the other methods are hard to find or costly.

Evaluating as many of the techniques as you can is sensible so you can make an informed decision on how to run production.

Tantec-UK and Ebble Manufacturing welcome any opportunity to help along the way, whether it’s providing small scale manufacturing support, or large scale machine installation.
